Product description:
Antminer APW12 PSU 12V-15V / APW12 1215a PSU / APW12 1215b PSU / APW12 1215c PSU / APW12 1215d PSU / APW12 1215e PSU / APW12 1215f PSU
There are many kinds of APW12 power supplies; please pay attention to the model and version when using them.
Currently, the main models of APW12 power supply are APW121215, APW121417, and APW12A; these types of power supply are incompatible.
APW12 1215a / 1215b / 1215c power supply is suitable for Antminer E9, D7, S19+, S19A pro, S19A, S19j pro, S19j, S19i, S19, S19 Pro, T19.
S19 series miner have different versions at home and abroad, please contact the sales staff to confirm the same power supply as your miner version before purchasing the APW12 PSU.
APW12 1215 power supply is a widely used power supply at present. Most of the 19 series models use this power supply. The 4-digit number 1215 behind APW12 represents the power supply’s output voltage is 12-15V. This power supply has many versions, including a b c d e f. The commonality is as follows:
1. APW121215a / b / c versions are universal with each other (no voltage feedback).
2. APW121215d / e / f versions are universal with each other (with voltage feedback).
3. APW121215d / e / f version can replace part of a / b / c by upgrading firmware, but a / b / c version cannot be used with d / e / f replacement.
APW12 1215a PSU suit for S19+, S19A, S19A PRO, S19J, S19J PRO, S19I, T19, S19PRO, D7, E9.
APW12 1215e PSU suit for Antminer S19XP.
APW12 1215g PSU suit for Antminer S19jPro-A, S19Pro-A.
Reminder: When replacing the power supply, pay attention to the model and version of the original power supply. Avoid replacement errors, which will cause the miner to be unusable or cause burning.
Specifications :
| OUT1 |
DC Voltage |
12V-15V |
| Rated Current(220 V input) |
233A |
| Ripple & Noise |
<1% |
| Line Regulation |
<1% |
| Load Regulation |
<1% |
| Setup Time |
<2S |
| Short Circuit Protection |
>10mS |
| OUT2 |
DC Voltage |
12.3V |
| Rated Current(220 V input) |
15A |
| Ripple & Noise |
<1% |
| Voltage Accuracy |
12.2V—12.4V |
| Line Regulation |
<1% |
| Load Regulation |
<1% |
| Setup Time |
<2S |
| Short Circuit Protection |
>10mS |
| Input |
Voltage Range |
200-240V AC |
| Frequency Range |
47-63Hz |
| Power Factor |
>0.99(full load) |
| Leakage Current |
<1.5mA（220V 50Hz） |
| Protection |
Low-voltage Input |
80-89V AC |
| Output Short Circuit |
Yes |
| Overheat Protection |
Yes |
| Over-current Output |
291A-350A
（protection value varies under different voltage） |
| Environment |
Operating Temperature |
-20-45℃ |
| Operating Humidity |
20%-90%RH（non-condensing） |
| Altitude |
< 2000m |
| Structure |
Dimensions |
254.6mm*251.6mm*63mm |
| Net Weight |
3.6KG |
|
Cooling System |
forced‐air cooling |
|
Noise |
45dBA |
